Novinka:Electronics Weekly: Your chance to win an STM32L4 ...
(Kategória: Média vo svete)
Zaslal EdizonTN

Britský portál Electronics Weekly (since 1996), vychádzajúci v tlačenej podobe od roku 1960, dáva možnosť svojim čitateľom vyhrať jeden z troch vývojových kitov od STMicroelectronics STM32L4 Discovery Kit IoT Node 600.

  • Ultra-low- power STM32L4 Series MCUs based on ARM® Cortex® -M4 core with 1 Mbyte of Flash memory and 128 Kbytes of SRAM, in LQFP100 package
  • 64-Mbit Quad-SPI (Macronix) Flash memory
  • Bluetooth® V4.1 module (SPBTLE-RF)
  • Sub-GHz (868 or 915 MHz) low- power-programmable RF module (SPSGRF-868 or SPSGRF-915)
  • Wi-Fi® module Inventek ISM43362-M3G-L44 (802.11 b/g/n compliant)
  • Dynamic NFC tag based on M24SR with its printed NFC antenna
  • 2 digital omnidirectional microphones (MP34DT01)
  • Capacitive digital sensor for relative humidity and temperature (HTS221)
  • High-performance 3-axis magnetometer (LIS3MDL)
  • 3D accelerometer and 3D gyroscope (LSM6DSL)
  • 260-1260 hPa absolute digital output barometer (LPS22HB)
  • Time-of-Flight and gesture-detection sensor (VL53L0X)
  • 2 push-buttons (user and reset)
  • USB OTG FS with Micro-AB connector
  • Expansion connectors:
    • Arduino™ Uno V3
    • PMOD

  • Flexible power- supply options:
    • ST LINK USB VBUS or external sources

  • On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: mass storage, virtual COM port and debug port
  • Comprehensive free software HAL library including a variety of examples, as part of the STM32Cube package
  • Support of a wide choice of Integrated Development Environments (IDEs) including IAR™ , Keil® , GCC-based IDEs, ARM® mbed Enabled™
  • ARM® mbed Enabled™ (see

Blokové zapojenie

Farnel kit ponúka za 57,- Eur

Product Specifications
User Manual

viď. Adresár

Táto novinka je z mikroZONE
( )
